Physical Specs |
Size |
32 / 42 / 43 / 46 / 47 / 48 / 49 / 50 / 55 / 58 / 60 / 65 / 69.5 / 70 / 75 / 80 / 82 / 84 / 85 / 86 / 98 inch |
|
Color |
Black |
|
|
Material |
Aluminium alloy shell |
|
|
Transparency |
≥92% |
|
|
USB Cable |
1500mm |
|
|
Minimum Touch Object |
≥5mm |
|
|
Input Method |
Finger, Gloved Hand, or Opaque Object |
|
|
Interpolation Resolution |
32767*32767 |
|
|
Electrical Specs |
Scan Frequency |
60Hz |
|
Interface Type |
USB2.0(default) or RS232(optional) |
|
|
Touch Type |
Infrared 10/20 multi-point touch |
|
|
Output Format |
Coordinate output |
|
|
Response Time |
< 15ms |
|
|
Touch Accuracy |
2mm |
|
|
Working Voltage |
DC +5V+/-5% |
|
|
Operation Current |
< 180mA |
|
|
Power Supply |
USB |
|
|
Environmental Specs |
Working Temperature |
-10℃~55℃ |
|
Storage Temperature |
-20℃~65℃ |
|
|
Working Humidity |
20~80% RH,non-condensing |
|
|
Storage Humidity |
10~90% RH,non-condensing |
|
|
Light Immunity |
Anti-glare(optional) |
|
|
Reliability Specs |
Touch Times |
Unlimited |
|
Flammability |
UL94V-0 |
|
|
Operating System |
1. Windows 2000 / Windows XP / Win 7 / Win 8/ Win10 / Windows NT
2. Linux / Android / Mac
|
|
